Scanline
Features:
- Density: 1.15 g/cm³
- Melting Point: 165 °C
- Elongation at Break: approximately 20%
- Abrasion Resistance: Very high
- UV Resistance: High
- Water Absorption: Low
Application:
- In the fishing industry
- Anchoring lines for underwater equipment
- Buoy lines for fishing gear
Visit our webshop, ropestore.com:
Buy at ropestore.com(opens in a new tab)Contact us with an inquiry
Contact usLaid rope, Industry & Infrastructure, Construction, Commercial shipping, Pleasure boats & Maritime ropes
Description
Scanline is a type of rope made from a blend of fibers, with specific composition and properties.:
Material and properties: Scanline ropes are constructed with a blend of Danline fiber and polyester multifilament.
- “Silver ropes”: The ropes are also often called silver ropes and the combination of materials gives them a unique set of properties. Scanline typically has a color combination of light green and white, providing it with a distinctive and visible aesthetic.
- Sinking or floating: When mixed in a 50/50% ratio of Danline and polyester multifilament, the ropes do not float in water and have a density of 1.15 g/cm³. However, they can also be manufactured with different ratios to achieve floating Scanline ropes.
- Durability: The ropes have an elongation at break of approximately 20%. They are also known for their excellent UV resistance, making them suitable for outdoor use.
Application: Scanline is particularly suitable for the following purposes:
- In the fishing industry: Scanline is commonly used in the fishing industry for various applications. Its durability and strength make it a reliable choice for tasks such as mooring lobster pots.
- Anchoring lines for underwater equipment: Scanline can be used to secure equipment and objects located underwater. Its properties make it a robust rope capable of withstanding the stresses encountered in such environments.
- Buoy lines for fishing gear: Within the fishing gear industry, Scanline is used as buoy lines. Its durability and visibility in water make it a suitable choice for this application.
Advantages: Scanline benefits from combining the properties of Danline fiber and polyester multifilament. This unique composition provides the rope with a good balance of durability, UV resistance and strength, making it a versatile choice for various industries.
Specification
| Diameter [mm] | MBL [kp] | Weight [g/m] |
|---|---|---|
| 5 | 450 | 16 |
| 6 | 650 | 22 |
| 7 | 900 | 29 |
| 8 | 1150 | 37 |
| 10 | 1700 | 58 |
| 12 | 2400 | 83 |
| 14 | 3200 | 116 |
| 16 | 4200 | 151 |
| 18 | 5200 | 191 |
| 20 | 6300 | 236 |
MBL: minimum breaking load. Stated breaking loads apply to new rope.
